MLOps with vetiver

What is “production” anyway?

Hello!

@juliasilge

@juliasilge@fosstodon.org

youtube.com/juliasilge

juliasilge.com

Who are you?

• Data scientist 👩‍💻
• Statistician 🌟
• Data analyst 📈
• Software engineer 🛠️

If you develop a model…

you can operationalize that model!

If you develop a model…

you likely should operationalize that model!

Housing in Seattle 🏘️

glimpse(housing_prices)
#> Rows: 21,613
#> Columns: 6
#> $ price       <dbl> 221900, 538000, 180000, 604000, 510000, 1225000, 257500, 2…
#> $ bedrooms    <int> 3, 3, 2, 4, 3, 4, 3, 3, 3, 3, 3, 2, 3, 3, 5, 4, 3, 4, 2, 3…
#> $ bathrooms   <dbl> 1.00, 2.25, 1.00, 3.00, 2.00, 4.50, 2.25, 1.50, 1.00, 2.50…
#> $ sqft_living <int> 1180, 2570, 770, 1960, 1680, 5420, 1715, 1060, 1780, 1890,…
#> $ yr_built    <int> 1955, 1951, 1933, 1965, 1987, 2001, 1995, 1963, 1960, 2003…
#> $ date        <dttm> 2014-10-13, 2014-12-09, 2015-02-25, 2014-12-09, 2015-02-1…

Housing in Seattle 🏘️

housing_wf
#> ══ Workflow [trained] ══════════════════════════════════════════════════════════
#> Preprocessor: Formula
#> Model: rand_forest()
#>
#> ── Preprocessor ────────────────────────────────────────────────────────────────
#> price ~ bedrooms + bathrooms + sqft_living + yr_built
#>
#> ── Model ───────────────────────────────────────────────────────────────────────
#> Ranger result
#>
#> Call:
#>  ranger::ranger(x = maybe_data_frame(x), y = y, num.trees = ~200,      num.threads = 1, verbose = FALSE, seed = sample.int(10^5,          1))
#>
#> Type:                             Regression
#> Number of trees:                  200
#> Sample size:                      11756
#> Number of independent variables:  4
#> Mtry:                             2
#> Target node size:                 5
#> Variable importance mode:         none
#> Splitrule:                        variance
#> OOB prediction error (MSE):       58092312589
#> R squared (OOB):                  0.5817825

What is MLOps? 🤔

MLOps is…

MLOps is…

a set of practices to deploy and maintain machine learning models in production reliably and efficiently

MLOps with vetiver

Vetiver, the oil of tranquility, is used as a stabilizing ingredient in perfumery to preserve more volatile fragrances.

MLOps with vetiver

library(vetiver)
v <- vetiver_model(housing_wf, "home-prices")
v
#>
#> ── home-prices ─ <bundled_workflow> model for deployment
#> A ranger regression modeling workflow using 4 features

Make it easy to do the right thing

• Robust and human-friendly checking of new data
• Track and document software dependencies of models
• Model cards for transparent, responsible reporting

MLOps is…

• Versioning
  • Managing change in models ✅
• Deploying
  • Putting models in REST APIs 🎯
• Monitoring
  • Tracking model performance 👀

Version your model

library(pins)
board <- board_connect()
board |> vetiver_pin_write(v)

https://pub.demo.posit.team/public/seattle-housing-pin/

Create a REST API

library(plumber)
pr() |>
  vetiver_api(v)
#> # Plumber router with 4 endpoints, 4 filters, and 1 sub-router.
#> # Use `pr_run()` on this object to start the API.
#> ├──[queryString]
#> ├──[body]
#> ├──[cookieParser]
#> ├──[sharedSecret]
#> ├──/logo
#> │  │ # Plumber static router serving from directory: /Library/Frameworks/R.framework/Versions/4.4-arm64/Resources/library/vetiver
#> ├──/metadata (GET)
#> ├──/ping (GET)
#> ├──/predict (POST)
#> └──/prototype (GET)
## next pipe to `pr_run()` for local API

Where does vetiver work?

• Posit’s pro products, like Connect: vetiver_deploy_rsconnect()

• AWS SageMaker: vetiver_deploy_sagemaker()

• A public or private cloud, using Docker: vetiver_prepare_docker()

https://pub.demo.posit.team/public/seattle-housing/

Monitor your model

new_metrics <-
  augment(v, housing_val) |>
  vetiver_compute_metrics(date, "week", price, .pred)

vetiver_pin_metrics(
  board,
  new_metrics,
  "julia.silge/housing-metrics",
  overwrite = TRUE
)
#> # A tibble: 90 × 5
#>    .index                 .n .metric .estimator  .estimate
#>    <dttm>              <int> <chr>   <chr>           <dbl>
#>  1 2014-11-02 00:00:00   224 rmse    standard   206519.
#>  2 2014-11-02 00:00:00   224 rsq     standard        0.414
#>  3 2014-11-02 00:00:00   224 mae     standard   139904.
#>  4 2014-11-06 00:00:00   373 rmse    standard   222259.
#>  5 2014-11-06 00:00:00   373 rsq     standard        0.555
#>  6 2014-11-06 00:00:00   373 mae     standard   150022.
#>  7 2014-11-13 00:00:00   427 rmse    standard   253473.
#>  8 2014-11-13 00:00:00   427 rsq     standard        0.562
#>  9 2014-11-13 00:00:00   427 mae     standard   145938.
#> 10 2014-11-20 00:00:00   376 rmse    standard   251856.
#> # ℹ 80 more rows

Monitor your model

new_metrics |>
  ## you can operate on your metrics as needed:
  filter(.metric %in% c("rmse", "mae"), .n > 20) |>
  vetiver_plot_metrics() +
  ## you can also operate on the ggplot:
  scale_size(range = c(2, 5))

https://pub.demo.posit.team/public/seattle-housing-dashboard/

Using vetiver

• allows those new to MLOps to get started quickly
• supports scaling safely as an org matures

What does vetiver do?

• Version

• Deploy

• Monitor

your R and Python models

MLOps is…

a set of practices to deploy and maintain machine learning models in production reliably and efficiently

Why should data practitioners be excited about MLOps?

• Connect your work to the “real world”
• Scale your impact

Learn more

• Documentation at https://vetiver.posit.co/

• Isabel Zimmerman’s talk from rstudio::conf() 2022 on Demystifying MLOps

• Webinar by Julia and Isabel for Posit Enterprise Meetup

• Julia’s screencast on deploying a model with Docker

• Julia’s talk from posit::conf() 2023 on Reliable maintenance of ML models

• End-to-end demos from Posit Solution Engineering in R and Python
